33kV 70kN Polymer Disc Insulator B&S type
₹280.00
| Disc Rating | 70 kN |
| Material | Composite Polymer |
| Rated Voltage | 33000 V |
| Creepage Distance | 900 mm |
| Core Material | ECR Rod |
| Housing Material | Polymer |
| End Fitting | Ball Socket |
| End Fitting Type | Ball and Socket |
| Usage/Application | distribution line |
| Number of Discs | 8 Discs |
| Standard | IEC 61109 |
| Mechanical Strength | 70kN |
| Application | Distribution, 11 kV Line, Transmission, 33 kV Line, Substation |
| Color | Grey |
| Minimum Creepage Distance | 900mm |
| Packaging Type | Corrugated Boxes |
| Country of Origin | Made in India |
33kV Composite Polymer Disc insulator B&S type, also called Silicone Rubber Suspension insulator or Composite Polymeric Tension insulators having ball and socket type end fitting or Long Rod insulator.
Our high voltage electrical insulator conforms to IEC:61109 (latest amendemend).
Suitable for application on 33kV or 36kV overhead power/ electrical/ energy/ high voltage distribution/ transmission lines or systems and substations. Withstanding Tensile load of 70kN.
Make: Rashtriya Electrical
We are manufacturers based in India. We supply all across India, Nepal, Bhutan, Myanmar, Bangladesh, Sri Lanka, the Middle Eastern and Africa.
